Pass-through temperature measuring door (RGY-8000A)

Features:

Temperature sensor probe: thermal infrared imaging probe, which has the advantages of high sensitivity, high pixel, high resolution area array imaging, etc.;

High pass rate: normal and slow walk through, face side view indicator light, pass rate ≈ 40-60 people/min;

Prevent missed inspection: The product design is ergonomic, which ensures that the inspected person cannot avoid the probe;

Detection accuracy: The detection result can be accurate to two decimal places, under normal room temperature, the temperature error is ±0.5℃.

Irradiation angle: large-area conical sector.

System function: when passing people, green light prompts; when high temperature alarms, red light prompts; number of people recording;

Sound and light alarm: When the subject passes through the temperature measurement door, when the body temperature is abnormal, the red signal light flashes, and a sound prompt is issued to the detection personnel, and the number of alarms can be stored.

Intelligent statistics: intelligent passenger flow and alarm counting functions, which can automatically count the number of people passing by and the number of alarms;

Very low power consumption: less than 13W under normal working power;

Detection height: The probe can move up and down to adapt to people of different heights and ages;

Simple to use: portable installation, ready to use;

Scope of application: Widely used in railway stations, bus stations, hospitals, schools, office buildings and other public places.

technical parameter:

Working mode: 01 normal passing mode; 02 jogging side mode; 03 stop mode;

Detection distance: <50CM

Temperature measurement range: 25℃~48℃;

Temperature measurement error: ±0.5°C (at room temperature), ±0.3°C in a specific mode (at constant room temperature)

Resolution: 0.02℃

Working temperature: -25℃~55℃;

Working humidity: 95%, no condensation;

Working voltage: wide voltage AC180-250V, 50-60HZ;

Power: <20W;

Net weight: 50KG;

Channel size: 1950mm (height) × 620mm (width) × 500mm (depth);

Dimensions: 2150mm (height) × 700mm (width) × 500mm (depth).
